Dri-Scope Aid® Cabinet

Convert your existing scope cabinet into an automatic scope drying system

ANSI/AAMI ST91:2021 states that-The endoscope and its components should be dried after completion of the cleaning and disinfection process. Flexible endoscopes with channels should be dried for a minimum of 10-minutes with pressure-regulated forced instrument air or a minimum of HEPA-filtered air (Ofstead, 2018; Barakat, 2018; Perumpail, 2019; Alfa, 1991).

  • Constant Flow
  • Consistent Pressure
  • Repeatable Results

The Dri-Scope Aid® Cabinet supplies HEPA-filtered air or instrument air to all internal channels to aid in drying endoscopes with an automated drying cycle for improved turn-around time, and a continuous venting cycle for overnight storage. The Dri-Scope Aid® Cabinet converts your scope cabinet into a complete drying system.

Features & Benefits

  • Significantly improves drying of internal channels
  • HEPA filter offers a 99.97% retention rate of particles that have a size >0.3μm
  • Available model for connection to instrument air
  • Provides constant air delivery through all internal endoscope channels
  • Automatic high pressure shutoff
  • Fulfills forced air recommendations
  • Self adjusting high pressure regulation
  • Short drying cycle for quick turn-around time
  • Continuous venting cycle for overnight storage

Ease of operation

  • Hands-free operation
  • Visual display of purging times
  • Fits most existing scope cabinets
  • Simple to attach individual scope connectors
  • Works with major endoscope brands
  • Filter replacement indicator light
  • Dries 1-16 endoscopes


1840 Series Wall Pump

Unit Size:
5.75 H x 10.24 W x 4.23 D (inches)
146.1 H x 260.1 W x 107.4 D (mm)

Unit Weight:
6.5 lbs (2.9 kg)

1840 Series Ceiling Pump

Unit Size:
4.23 H x 10.24 W x 5.75 D (inches)
107.4 H x 260.1 W x 146.1 D (mm)

Unit Weight:
6.5 lbs (2.9 kg)

23 Series Manifold
(10 port system shown)

Unit Size:
6.25 H x 23 W x 2.2 D (inches)
158.8 H x 584.2 W x 55.9 D (mm)

Unit Weight:
7 lbs (3.2 kg)

33 Series Manifold
(16 port system shown)

Unit Size:
6.25 H x 33 W x 2.2 D (inches)
158.8 H x 838.2 W x 55.9 D (mm)

Unit Weight:
11 lbs (5.0 kg)

Disposable Port Connector Kits

(Fuji, Olympus, Pentax, and Storz)

Contact Us For More Information
